Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger

I'm Online Chat Now

Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger

Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger
Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger

Large Image :  Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger

Product Details:
Place of Origin: Shanghai
Brand Name: KOKA
Certification: ISO9001 2015
Model Number: KK-CH020
Payment & Shipping Terms:
Minimum Order Quantity: 1000PCS
Price: Sent email to us
Packaging Details: Pallet Packing,customized requirement
Delivery Time: 10-25 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 999999/pcs/month

Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger

Description
Material: Carbon Steel/ss304/ss316/Copper/Aluminum Surface Treatment: Zinc Plated /Galvanized/HDG
Usage: Pipe Clamp MOQ: 1000pcs
Service: OEM ODM Sample: Available
Certification: ISO9001-2015 Package: Carton Box

Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger



Products: Clevis Hanger

A Clevis hanger is a pipe accessory that loops around a pipe in order to support it. Loop hangers are similar to clevis hangers, split ring hangers, and clamp hangers, which are all examples of pipe hangers, but there are qualities that help to set loop hangers apart from the rest.

The design of loop hanger is simple but effective, looping around a pipe and connecting to a beam or ceiling for support. Loop hangers have keyed insert nuts to guarantee the loop hanger and insert nuts stay together. This type of pipe support is highly recommended for the suspension of non-insulated, stationary pipe lines.



Features:

Size range: 1/2 inches thru 24 inches
Material: Carbon steel
Finish: Black or galvanized: furnished galvanized unless otherwise specified.
Max. temp: 650°F.
Feature: Designed with the yoke on outside of lower U-Strap so the yoke cannot slide toward the center of the bolt, thus bending of the bolt is minimized.

Complies with Manufactures' Standardization Society (MSS) SP-58 & SP-69 (Type 1). Complies with Federal Specifications A A-1192A (Type 1). Complies with Underwriters' Laboratories (UL) & (cUL) (062311- EX15800),

Applications:

For the suspension of non-insulated, stationary pipe lines.



Certification:

Part No. Pipe Size Thickness(mm) Ø(mm) Finish
KK-CH020 3/4” 2.5 11 EG/HDG/SS304/SS316
KK-CH025 1” 2.5 11 EG/HDG/SS304/SS316
KK-CH032 1-1/4” 2.5 11 EG/HDG/SS304/SS316
KK-CH040 1-1/2” 2.5 11 EG/HDG/SS304/SS316
KK-CH050 2” 2.5 11 EG/HDG/SS304/SS316
KK-CH065 2-1/2” 3 14 EG/HDG/SS304/SS316
KK-CH080 3” 3 14 EG/HDG/SS304/SS316
KK-CH090 3-1/2” 4 14 EG/HDG/SS304/SS316
KK-CH100 4” 4 17 EG/HDG/SS304/SS316
KK-CH125 5” 4.5 17 EG/HDG/SS304/SS316
KK-CH150 6” 4.5 20 EG/HDG/SS304/SS316
KK-CH200 8” 4.5 20 EG/HDG/SS304/SS316
KK-CH250 10” 6 23.7 EG/HDG/SS304/SS316
KK-CH300 12” 6 23.7 EG/HDG/SS304/SS316
KK-CH350 14” 6 27 EG/HDG/SS304/SS316
KK-CH400 16” 6 27 EG/HDG/SS304/SS316
KK-CH450 18” 6 32 EG/HDG/SS304/SS316
KK-CH500 20” 8 33.2 EG/HDG/SS304/SS316
KK-CH600 24” 8 33.2 EG/HDG/SS304/SS316



Product Show:

Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger 0  Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger 1



Package:

Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger 2  Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger 3

Zinc Plated Pipe Hanger 3/4'' 24'' Clevis Hanger 4



FAQ:

Q1: Are you manufacturer?
A: Yes,we are factory ,We have stamping and injection factories.
Q2: What services can we offer?
A: We can OEM and ODM,We have a strong design team,we can provide drawing.
Q3: What information need for quotation?
A: For example:

1: what material(carbon steel/Q235/SS304/SS316)

2 : what size do you need ?
3: what surface finished( zinc plate/HDG/powder coating/copper plated)?
Q4: Do you provide free samples?
A: Yes ,you can get the free samples
Q5: What is your payment terms?
A: 30% T/T deposit,balance will be against each copy of B/L;
Q6: How about the delivery time?
A: According to your order list and quantity,Normally delivery in 20-25days.
